Comprehensive Range of Label Applicators
▪ Modular design allows many configurations
▪ Swiss-made to the highest industrial standards
▪ 95mm, 160mm and 250mm wide models
- Precision, reliability and flexibility come as standard with all Collamat label applicators. The range includes five standard model ranges each of which can be configured to suit a wide variety of applications. The choice of applicator modules includes:
▪ Fixed beak with spring loaded roller, fixed roller or brush
▪ Electro-magnetic beak for labelling into recessed surfaces
▪ Tamp applicator for maximum precision
▪ Blow applicator for fragile and uneven products
▪ Custom applicators for special requirements
The flexible, modular design allow a choice of print engines and coders to be fitted to turn a Collamat applicator into a print-and-apply system either when initially installed or at a later date. In addition, the modular design allows Collamat applicators to be converted from right to left hand or vice versa.
Which Collamat to choose...
| |
2610
|
3600
|
6600
|
7600
|
NG50
|
NG100
|
| Label width: |
95mm |
95/160mm |
95/160mm |
95/160mm |
100/180mm |
100/180/250mm |
| Max speed: |
15m/min |
20m/min |
30m/min |
40/50m/min |
50m/min |
100m/min |
| Accuracy: |
+/-1mm |
+/-1mm |
+/-1mm |
+/-1mm |
+/-0.5mm |
+/-0.5mm |
| Max. roll size: |
250mm |
350mm |
350mm |
350mm |
400mm |
400mm |
| Powered unwind: |
No |
No |
No |
No |
Optional |
Optional |
| Shaft Encoder: |
No |
No |
Optional |
Optional |
Optional |
Optional |
| Web break sensor: |
No |
Optional |
Optional |
Optional |
Optional |
Optional |
| Low label sensor: |
No |
Optional |
Optional |
Optional |
Optional |
Optional |
| LAN interface: |
No |
No |
No |
No |
Yes |
Yes |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
